Video and Image Processing Suite Overview
1
2015.05.04
UG-VIPSUITE
The Altera
®
Video and Image Processing Suite collection of IP cores ease the development of video and
image processing designs.
You can use these IP cores in a wide variety of image processing and display applications.
Attention: Altera has scheduled the following IP cores for product obsolescence and will discontinue
support for it.
• Clipper
• Test Pattern Generator
Altera recommends that you do not use these IP cores in new designs. For more information
about Altera’s current IP offering, visit the Altera
web page.
Table 1-1: Video and Image Processing Suite IP Core Features
The table lists the IP cores in the Video and Image Processing Suite.
IP Core
Feature Support
Pixels in Parallel
4:2:2 Support
Interlaced
2D FIR Filter
No
No
No
Alpha Blending
Mixer
No
Yes
Yes
(1)
Chroma Resampler
No
Yes
No
Clipper
No
Yes
Yes
(2)
Clipper II
Yes
Yes
Yes
(2)
Clocked Video
Input (CVI)
No
Yes
Yes
Clocked Video
Input II (CVI II)
Yes
Yes
Yes
(1)
The IP core accepts interlaced input streams but they are treated as progressive inputs. Consequently, you
require external logic to synchronize the input fields and prevent the mixing of F0 fields with F1 fields.
(2)
The IP core accepts interlaced inputs but they are treated as progressive inputs.
©
