PLANET WGSW-52040 - Manual (Page 412)

mac-authentication-bypass
spoofing-garp-check enable
no mac-authentication-bypass
spoofing-garp-check enable
Enable the spoofing-garp-check function,
MAB function will not deal with
spoofing-garp any more; the no command
disables the function.
authentication mab {radius | none}
no authentication mab
Configure the authentication mode and
priority of MAC address, the no command
restores the default authentication mode.
50.3 MAB Example
Example:
The typical example of MAB authentication function:
Update Server Radius Server Internet
Eth1/1 Eth1/2 Eth1/3
Switch1
PC1 PC2 Printer
Switch2
Eth1/3 Eth1/2 Eth1/1
Ethernet1/4
Ethernet1/4
Figure 50-1: MAB application
50-191
