MVI56-AFC ♦ ControlLogix Platform MVI56-AFC Sample Logic
Liquid and Gas Flow Computer User Manual
ProSoft Technology, Inc. Page 207 of 316
February 25, 2011
The sample ladder uses the following Block Sequence Number to generate
output blocks:
Block Sequence Number Description
1 Process variables, enable/disable (all Meters).
Write Molar Analysis (Meter 1) and read profile (Meter 1)
2 Process variables, enable/disable (all Meters).
Write Molar Analysis (Meter 2) and read profile (Meter 2)
3 Process variables, enable/disable (all Meters).
Write Molar Analysis (Meter 3) and read profile (Meter 3)
4 Process variables, enable/disable (all Meters).
Write Molar Analysis (Meter 4) and read profile (Meter 4)
5 Process variables, enable/disable (all Meters).
Write Molar Analysis (Meter 5) and read profile (Meter 5)
6 Process variables, enable/disable (all Meters).
Write Molar Analysis (Meter 6) and read profile (Meter 6)
7 Process variables, enable/disable (all Meters).
Write Molar Analysis (Meter 7) and read profile (Meter 7)
8 Process variables, enable/disable (all Meters).
Write Molar Analysis (Meter 8) and read profile (Meter 8)
9 Process variables, enable/disable (all Meters).
Write Molar Analysis (Meter 9) and read profile (Meter 9)
10 Process variables, enable/disable (all Meters).
Write Molar Analysis (Meter 10) and read profile (Meter 10)
11 Process variables, enable/disable (all Meters).
Write Molar Analysis (Meter 11) and read profile (Meter 11)
12 Process variables, enable/disable (all Meters).
Write Molar Analysis (Meter 12) and read profile (Meter 12)
13 Process variables, enable/disable (all Meters).
Write Molar Analysis (Meter 13) and read profile (Meter 13)
14 Process variables, enable/disable (all Meters).
Write Molar Analysis (Meter 14) and read profile (Meter 14)
15 Process variables, enable/disable (all Meters).
Write Molar Analysis (Meter 15) and read profile (Meter 15)
16 Process variables, enable/disable (all Meters).
Write Molar Analysis (Meter 16) and read profile (Meter 16)
17 Modbus Gateway Block 0 (if configured)
18 Modbus Gateway Block 1 (if configured)
19 Modbus Gateway Block 2 (if configured)
20 Modbus Gateway Block 3 (if configured)
21 Modbus Gateway Block 4 (if configured)
22 Modbus Gateway Block 5 (if configured)
23 Modbus Gateway Block 6 (if configured)
24 Modbus Gateway Block 7 (if configured)
25 Modbus Gateway Block 8 (if configured)
25 Modbus Gateway Block 9 (if configured)
Each Process Block (Block Sequence Number 1 to 16) is organized as follows:
