14.3 Wedge Meter Applications
For Wedge Meter applications you must convert some parameters from the
meter manufacturer’s data sheet before entering these values to the AFC
Manager. The following spreadsheets can be used to calculate the AFC Manager
parameters according to the meter manufacturer as follows:
Filename Application
WEDGE_ABB.xls ABB Wedge Meter
WEDGE_PRESO.xls PRESO Wedge Meter
You must initially configure the meter as a differential type. Then you must
configure it as a V-Cone Device (Meter Configuration / Calculation Options).
Refer to the spreadsheet for instructions on how to enter the correct values into
AFC Manager.
