Grass Valley GV STRATUS Installation v.3.1 - Manual (Page 135)

Description Setting or button
The type of K2 device that you can choose is either SAN client or
Standalone client. Type of K2 device
The K2 SAN system name, if you chose SAN client. SAN Name
The primary device in the SAN that you want to use with the Scheduler. Primary Device
The K2 Standalone system name, if you chose Standalone Client. Select K2 Standalone
The channel you are using to record, such as C1, C2, C3, etc. Ensure
that the channel will not be in Continuous Record mode when you are
using it for Scheduler record. This setting is persistent in its control of
K2 system channels and cannot be overridden by K2 AppCenter or
other GV STRATUS application tools, such as Channel Panel. Client Channel
The router destination for the channel. If you haven't configured your
router sources or are not using a router in your operation, the drop-down
list is empty. Router Destination
The timecode source for the channel. You can choose from Internal,
LTC, ancLTC, Time of Day, VITC, and ancVITC as appropriate for
the HD/SD configuration of the channel. Timecode Format
User name, domain, and password to connect to the K2 device, if
required to do so. Account used to connect
to K2 Device
Related Topics
About timecode source and clock synchronization on page 164
Feed Ingest Location Setup settings
These settings are optional on GV STRATUS systems.
To locate these settings, click Applications | Feed Ingest | Location Setup
2013 12 19 GV STRATUS Installation and Service Manual 135
Reference to GV STRATUS Control Panel settings
