3. Right-click the selected device or devices and select Ping .
The Ping Devices dialog box opens and lists the selected device or devices.
The Ping Devices dialog box reports the progress and results of the ping command per device.
SiteConfig control network setup for client PC
Only systems with GV STRATUS client PCs on the control network require this process. Add client
PCs to SiteConfig using device discovery.
Discovering devices with SiteConfig
Prerequisites for this task are as follows:
• The Ethernet switch or switches that support the control network are configured and operational.
If multiple switches, ISLs are connected and trunks configured.
• The PC that hosts SiteConfig is communicating on the control network.
• There are no routers between the PC that hosts SiteConfig and the devices to be discovered.
• Devices to be discovered are Windows operating system devices, with SiteConfig support
installed.
• Devices are cabled for control network connections.
• If discovering a device with Microsoft Windows Server 2008 operating system, the device must
have an IP address, either static or DHCP supplied.
1. Open SiteConfig.
2. In the toolbar, click the discover devices button.
The Discover Devices dialog box opens.
A list of discovered devices is displayed.
60 GV STRATUS Installation and Service Manual 2013 12 19
Commissioning a system
