Identifying assets affected by rules, Adding a thumbnail marker, Adding a carbon coder transcode profile – Grass Valley GV STRATUS Installation v.3.1 User Manual
Page 289
3. Right-click an upcoming job and select
Cancel
to stop the GV STRATUS system from running
the job.
4. Right-click completed job and select
Delete
to remove it from the list of jobs.
5. Click the
Refresh
button
if the Jobs List is not updated.
Identifying assets affected by rules
In the GV STRATUS application you can determine if the Rules Engine has applied a rule to an
asset. You do this by searching on the name of the rule. Therefore, create rule names that contain a
unique term on which you can search.
In the GV STRATUS application, do an Advanced Search with conditions such as the following:
Rules Applied | contains |
<unique term>
For example, if all your export rule names contain the unique term "export", then your search
condition is as follows:
Rules Applied | contains | export
The search returns a list of all the assets that have be affected by rules with the unique term in their
name.
Adding a thumbnail marker
When configuring an export rule, if you choose to export thumbnails, you must define the thumbnails
for an exported asset. An export thumbnail is defined by a
tn
marker added to the source asset.
Multiple thumbnails are exported when the source asset has multiple
tn
markers.
1. Load the asset into a GV STRATUS component that adds markers, such as Inspector, Source
Viewer, or Channel Panel.
2. In the asset, identify the image to use as an export thumbnail.
3. Add a marker at the image location and name the thumbnail
tn
.
The thumbnail at the marker is exported by the export rule.
Adding a Carbon Coder transcode profile
GV STRATUS rules support transcode profiles you create using third party applications. This topic
provide steps for the Harmonic ProMedia
™
Carbon (formerly Carbon Coder
™
) application.
At the time of this writing, the following formats are supported as source formats for transcoding
by the Harmonic ProMedia
™
Carbon (formerly Carbon Coder
™
) application:
•
DV25/50
•
DVCAM
•
MPEG I-frame
•
MPEG long GoP
•
DVCPRO HD
•
MPEG XDCAM
•
AVC-Intra
•
DNxHD
2013 12 19
GV STRATUS Installation and Service Manual
289
Administering and maintaining the GV STRATUS system
