Archive system set up process
Only systems with an archive system require this process. Configure the archive system with the
K2 Summit/SAN system, use SabreTooth to install the STRATUS-ARCHIVE license, and in GV
STRATUS Control Panel configure an archive MDI.
Use the topics in this section that are appropriate for the type of archive system you are using with
your GV STRATUS system.
Configuring DIVA
Before you begin, verify the following:
• The DIVA server must have sufficient storage for archived clips.
• The DIVA server must be connected to the Control and streaming/FTP networks.
• The K2 system must be assigned with the role of FTP Server.
• Verify that K2 systems, GV STRATUS Core server, and the archive device can all communicate
with each other on the streaming/FTP network. Use the
ping command at the MS-DOS command
prompt to test each device's streaming/FTP network name, which includes the _he0 suffix.
1. Log on to the DIVA server.
2. Launch the Configuration Utility on the DIVA server.
3. Click the Open connection button on the toolbar to connect to the DIVA database.
The log on dialog box opens.
4. Enter your user name and password, and click OK .
