Table 3: Mechanical specifications
Specification Characteristic
Rack-mount Cabinet Type
1 Rack units
482.4 (w) x 42.8 (h) x 683.7 (d) mm External Dimensions
Maximum 18.6kg , 40.96 lbs Weight
Table 4: Power specifications
495W AC 750W AC 1100W AC 1100W DC Specification
6.5A-3A 10A-5A 12A-6.5A 32A Current
consumption
100-240VAC 100-240VAC 100-240VAC -48V to -60V DC Supply voltage
50/60Hz 50/60Hz 50/60Hz N/A Frequency
1908 2843 4100 4416 Heat dissipation
(BTU/hr max)
55A 55A 55A 55A Maximum inrush
current
K2 Summit 3G Rack specifications
Use the following specifications to determine load, spacing, power, and other factors when planning
system racks. These specifications apply to K2 Summit 3G chassis.
Table 5: Mechanical specifications
Specification Characteristic
Rack-mount Cabinet Type
2 Rack units
447 x 617 x 89 mm External Dimensions
25.0 kg maximum Weight
Table 6: Power specifications
Specification Characteristic
Dual, redundant Power conditions
90 to 260V auto-range, 47-63Hz Mains Input Voltage
2013 12 19 GV STRATUS Installation and Service Manual 29
