7. To modify planned settings, do the following:
a) Select the network settings and click Edit .
The Edit IP Address dialog box opens.
b) Edit IP address settings as follows:
For network interface Network Connection Setting...
Control is required Network
Static is recommended. Address Allocation
The IP address for this interface on the network. Required. IP Address
The networks listed in the Edit IP Address dialog box are those currently defined in the system
description, with available settings restricted according to the network definition. If you
require settings that are not available, you can close dialog boxes and go to the
Network
Configuration | Networks tab to modify network settings, then return to the Edit IP Address
dialog box to continue.
8. When you have verified that the planned settings are correct, click OK , then Yes to apply settings
to the device and close.
A Contacting Device message box reports progress.
