Complete system set up and configuration
Complete system installation process
Use the following list if you must change the system configuration or if there are system setup or
configuration processes that are incomplete. Browse this process and do the appropriate items.
1. Rack, cable, and power on process on page 27. All systems require this process.
2. K2 system set up process on page 318. All systems require this process.
3. Express/Core server set up process on page 320. All systems require this process. Use SiteConfig
for network setup and software install. On the GV STRATUS server with role of Common
Services, use SabreTooth and install GV STRATUS licenses.
4. Proxy Server/Storage set up process on page 329. Only systems with proxy on the K2 SAN (A1)
or with proxy on dedicated Proxy Storage (B1, C1) require this process. Use SiteConfig for
network setup and software install, then use K2Config for SAN setup.
5. GV STRATUS Control Panel system configuration process on page 357. All systems require this
process. Use GV STRATUS Control Panel to configure the GV STRATUS system for your site's
workflow.
6. Customer network, licenses, and roles process on page 44. All systems require this process. Set
up the GV STRATUS Core server on the customer's network and assign GV STRATUS licenses
and roles to the customer's groups and users.
7. Client PC set up process on page 46. All systems require this process. Add the customer's GV
STRATUS client PCs to the system.
8. SiteConfig software deployment process on page 374. All systems require this process when
updating to new versions of Grass Valley product software.
9. Proxy Encoder set up process on page 391. Only systems with a Proxy Encoder require this
process. Use SiteConfig for network setup and software install. On the GV STRATUS Proxy
Encoder, use SabreTooth and install the STRATUS-PROXYENCODER license. Then use
K2Config for SAN setup.
10. Conform Server set up process on page 406. Only systems with a Conform Server require this
process. Use SiteConfig for network setup and software install. On the Conform Server, use
SabreTooth and install the STRATUS-CONFORM license. Then use K2Config for SAN setup.
11. Archive system set up process on page 421. Only systems with an archive system require this
process. Configure the archive system with the K2 Summit/SAN system, use SabreTooth to
install the STRATUS-ARCHIVE license, and in GV STRATUS Control Panel configure an
archive MDI.
12. EDIUS XRE Server set up process on page 436. Only systems with an EDIUS XRE Server require
this process. Use SiteConfig for network setup and software install. On the EDIUS XRE Server,
use EDIUS licensing to license the server. Then use K2Config for SAN setup.
