Specification Characteristic
Microsoft Windows 7 64-bit Operating system
Version 4.5 Microsoft .NET Framework
DirectX 9 compatible Other support
Cabling for high-resolution client PC
Only systems with GV STRATUS client PCs on the K2 media (iSCSI) network require this process.
Connect the PC to the control network and to the media network.
A GV STRATUS client PC on the K2 media (iSCSI) network must have at least two Ethernet 1000
Base-T network interfaces.
• Connect one network interface to the control network.
• Connect one network interface to the media network.
Set firewall for application ports
If there is a firewall between systems running client applications and those application's servers,
you must configure the firewall to ensure communication between client and server.
Related Topics
Ports and services mapping on page 311
GV STRATUS application ports
Port settings must be open so that the GV STRATUS client application can connect to servers as
follows:
Protocol: TCP. Traffic: HTTP. Used by any GV STRATUS server or MediaFrame
server. Used by GV STRATUS Core Services. 80
Protocol: TCP. Used by GV STRATUS Ingest services. Used by GV STRATUS
Ingest DB Management Service. Used by GV STRATUS Core Server. 3838
Protocol: TCP. Used by GV STRATUS Ingest services. Used by GV STRATUS
Core Server. 3839
Protocol: TCP. Traffic: HTTP. Used by GV STRATUS Router Config service for
configuration. Used by GV STRATUS Ingest Services. Used by GV STRATUS
Core Server. 7144
Protocol: TCP. Traffic: HTTP. Used by router config data service. Used by GV
STRATUS Ingest Services. Used by GV STRATUS Core Server. 7145
Protocol: TCP. Used by GV STRATUS Router Controller service. Used by GV
STRATUS Ingest Services. Used by GV STRATUS Core Server. 7213
Protocol: TCP. Traffic: HTTP. Used by GV STRATUS Common Services, including
preferences, licensing, authorization. Used by Proxy config, Web Monitor data
service. Used by GV STRATUS Core Server. 8000
