When you have multiple Summit MDIs, they must each have their own process port number. For
this purpose, numbers 9160 - 9169 increment in the
Port field.
Description Setting or button
The Managed Device Interface (MDI) type to which these settings
apply. MDI Type
A name for this instance of the MDI type. Do not use spaces in the
MDI name. MDI Name
The name of the GV STRATUS server that hosts this MDI. Hostname of device
running the MDI
The process port for this instance of the MDI type. Each instance must
have its own process port. Port numbers must be in range 9160-9169. Port number
94 GV STRATUS Installation and Service Manual 2013 12 19
Reference to GV STRATUS Control Panel settings
