• If using hosts files, the server's Control and FTP IP addresses must be added to your K2/GV
STRATUS system hosts files. Hostnames for FTP IP addresses must have the
_he0 suffix.
1. Verify that K2 systems, GV STRATUS Core server, and the archive device can all communicate
with each other on the streaming/FTP network. Use the ping command at the MS-DOS command
prompt to test each device's streaming/FTP network name, which includes the _he0 suffix.
2. On the server that runs the FileZilla FTP service, check to see if IIS is installed. If it is installed,
either uninstall it or disable it.
3. On the server that runs the FileZilla FTP service, on the C:\ drive, create a folder and name it
root .
4. It is recommended that you create the internal system account, which by default is GVAdmin,
in the Administrators group
5. Install the FileZilla Server software.
Install the latest version available on the Internet.
6. Open the FileZilla application.
7. When the Connect to Server window opens, do the following:
a) Verify that the Server Address defaults to 127.0.0.1.
b) Verify that the port defaults to 14147.
c) Enter the password for the internal system account, which by default is GVAdmin.
d) Select
Always connect to this server .
This disables the automatic opening of the Connect to Server window.
8. Click Edit | Settings | General Settings , and configure the Welcome message as follows:
a) Select Welcome message .
b) Delete all characters except for %v .
c) Click OK .
426 GV STRATUS Installation and Service Manual 2013 12 19
Complete system set up and configuration
