Purpose
Size
Drive letter
SQL
approximately 100 GB
(92.62 GB with Solid State Drives)
D
Storage for recovery disk image files
20 GB
E
GV STRATUS Core server: Fault Tolerant (FT)
The C: and E: partitions are on the first physical drive in the CPU/IO module.
Purpose
Size
Drive letter
System drive
116 GB
C
SQL
All space on remaining drives.
D
Storage for recovery disk image files
20 GB
E
Proxy server, Proxy Storage file system server
This server has two RAID 1 drives.
Purpose
Size
Drive letter
System drive
50 GB (default size of disk image)
C
SNFS
71 GB
D
Storage for recovery disk image files
20 GB
E
Proxy Encoder, Conform Server, EDIUS XRE Server, Workflow Server
This server has four RAID 5 drives.
Purpose
Size
Drive letter
System drive.
Also SNFS on EDIUS XRE Server.
50 GB (default size of disk image)
C
Proxy Encoder, Conform Server: SNFS
Workflow Server: SQL
All space on remaining drives. Over 1 TB.
D
Storage for recovery disk image files
20 GB
E
Related Topics
GV STRATUS system and server variants
on page 13
on page 20
