3. Configure XRE Node settings as follows:
a) From the Windows desktop, click Start | All Programs | Grass Valley | XRENode .
b) From the Windows desktop system tray, right-click XRENode and select Settings .
If system tray icons are not present, verify that EDIUS licensing is complete. Missing icons
can indicate the software is not licensed.
The XRENode setting dialog box opens.
c) For Node name enter the name of the XRE Node, as specified below.
For Server setting , the computer name is present by default.
d) Click Setting .
The Settings dialog box opens.
e) In the tree view, click Settings | Server settings .
f) Click Add .
The Server setting dialog box opens.
g) Make XRE Node settings, as follows.
Table 15: XRE Node settings
Value Setting
As desired, enter a name for the XRE node. Node name
Name: The local XRE Server name. It is recommended that you
enter the machine name.
Address: The local XRE Server IP address.
Port: The port assigned for communication with the EDIUS XRE
Server, as specified in GV STRATUS Control Panel EDIUS
Settings. The default port number is 1223.
Server setting
h) Click OK to save settings and close.
2013 12 19 GV STRATUS Installation and Service Manual 461
Complete system set up and configuration
