Adding a software role to a device
1. In the Software Deployment | Devices tree view, right-click the device and select Add Role .
The Add Role dialog box opens.
The Add Role dialog box displays only those roles that SiteConfig allows for the selected device
type.
2. Select the role or roles that you want to add to the device. Use Ctrl + Click or Shift + Click to
add multiple roles.
3. Click OK to save settings and close.
The new role or roles appear under the device in the tree view.
Removing a software role from a device
1. In the Software Deployment | Devices tree view, expand a device’s node to expose the roles
currently assigned to the device.
2. Right-click the role you want to remove and select Remove .
The role is removed from the device in the tree view.
Adding a device to a network with SiteConfig
You can use SiteConfig to configure network settings on a device.
After you have added the device to the SiteConfig system description, work through the topics in
this section to add the device to your network.
Discovering devices with SiteConfig
Prerequisites for this task are as follows:
• The Ethernet switch or switches that support the control network are configured and operational.
If multiple switches, ISLs are connected and trunks configured.
