148 YASKAWA ELECTRIC TOEP C710656 08B YASKAWA Power Regenerative Unit - R1000 Instruction Manual
A.1 Power Ratings
A.1 Power Ratings
Table A.1 Power Ratings (Three-Phase 200 V Class)
Table A.2 Power Ratings (Three-Phase 400 V Class)
Item
<1> Rated output capacity is calculated with a rated input voltage of 220 V.
Specification
Model 2A03P5 2A0005 2A0007 2A0010 2A0014 2A0017 2A0020 2A0028 2A0035 2A0053 2A0073 2A0105
Maximum Applicable Motor
Capacity [HP]
5 7 10 15 20 25 30 40 50 74 101 148
Rating
Rated Output
Capacity [HP]
<1>
5 7 9 13 19 23 27 38 47 71 98 141
Rating
Rated Output Current
(DC) [A]
14 20 27 41 55 68 81 112 138 207 282 413
Rated Input Current
(AC) [A]
10 15 20 30 41 50 60 83 102 153 209 306
Item
<1> Rated output capacity is calculated with a rated input voltage of 440 V.
Specification
Model 4A03P5 4A0005 4A0007 4A0010 4A0014 4A0017 4A0020 4A0028
Maximum Applicable Motor
Capacity [HP]
5 7 10 15 20 25 30 40
Rating
Rated Output Capacity
[HP]
<1>
5 7 9 13 19 23 27 38
Rating
Rated Output Current
(DC) [A]
7 11 15 22 30 36 43 58
Rated Input Current
(AC) [A]
5 8 11 16 22 27 32 43
Item
<1> Rated output capacity is calculated with a rated input voltage of 440 V.
Specification
Model 4A0035 4A0043 4A0053 4A0073 4A0105 4A0150 4A0210 4A0300
Maximum Applicable Motor
Capacity [HP]
50 60 74 101 148 215 295 422
Rating
Rated Output Capacity
[HP]
<1>
47 58 71 98 141 201 282 402
Rating
Rated Output Current
(DC) [A]
73 89 109 149 217 320 440 629
Rated Input Current
(AC) [A]
54 66 81 110 161 237 326 466
