B.2 Parameter Tables

YASKAWA ELECTRIC TOEP C710656 08B YASKAWA Power Regenerative Unit - R1000 Instruction Manual

167

Par

ame

te

r Li

st

B

o2-03

(507H)

User Parameter
Default Value

User Default Sel
0: No Change
1: Save User Init
2: Clear User Init

0: No change.
1: Set defaults. Saves parameter settings as default values
for a User Initialization.
2: Clear all. Clears the default settings that have been
saved for a User Initialization.

Default: 0
Min.: 0
Max.: 2

o2-04

(508H)

Unit Model
Selection

Inverter Model #

Enter the regenerative unit model. Setting required only if
installing a new control board.

Default:
Determined by unit
capacity.
Min.: –
Max.: –

o2-06

(50AH)

Operation Selection
when Digital
Operator is
Disconnected

Oper Discon Det
0: Disabled
1: Enabled

Determines the operation when the digital operator is
disconnected.
0: The regenerative unit continues operating if the digital
operator is disconnected.
1: A fault is triggered (oPr) and the motor coasts to stop.

Default: 1
Min.: 0
Max.: 1

o2-09

(50DH)

Reserved

o2-21

(81AH)

Unit Check

US signal check
0: Nomal
1: Start

Sets the operation for Unit Capacity Setting Error (oPE01).
Set this parameter to 1 to reset an oPE01 fault without
cycling the power supply.
0: Standard
1: Recheck regenerative unit (The parameter returns to 0
after it is set.)

Default: 0
Min.: 0
Max.: 1

o3: Copy Function

o3-01

(515H)

Copy Function
Selection

COPY SELECT
0: COPY SELECT
1: INV

→OP READ

2: OP

→INV WRITE

3: OP

←→INV

VERIFY

0: No action
1: Read parameters from the regenerative unit, saving them
onto the digital operator.
2: Copy parameters from the digital operator, writing them
to the regenerative unit.
3: Verify parameter settings on the regenerative unit to
check if they match the data saved on the operator.

Default: 0
Min.: 0
Max.: 3

o3-02

(516H)

Copy Allowed
Selection

Read Allowable
0: Disabled
1: Enabled

0: Read operation prohibited
1: Read operation allowed

Default: 0
Min.: 0
Max.: 1

o4: Maintenance Monitor Settings

o4-01

(50BH)

Cumulative
Operation Time
Setting

DrvElapsTimeCnt

Sets the value for the cumulative operation time of the
regenerative unit in units of 10 h.

Default: 0
Min.: 0
Max.: 9999

o4-02

(50CH)

Cumulative
Operation Time
Selection

ElapsTimeCntSet
0: Power-On Time
1: Running Time

0: Logs power-on time
1: Logs operation time when the regenerative unit output is
active (output operation time).

Default: 0
Min.: 0
Max.: 1

o4-03

(50EH)

Cooling Fan
Operation Time
Setting

FanElapsTimeCn

Sets the value of the fan operation time monitor U4-03 in
units of 10 h.

Default: 0
Min.: 0
Max.: 9999

o4-05

(51DH)

Capacitor
Maintenance Setting

BusCap Maint Set

Sets the value of the Maintenance Monitor for the
capacitors. See U4-05 to check when the capacitors may
need to be replaced.

Default: 0%
Min.: 0%
Max.: 150%

o4-07

(523H)

DC Bus Pre-Charge
Relay Maintenance
Setting DC Bus
Pre-Charge Relay
Maintenance Setting

ChrgCircMaintSet

Sets the value of the Maintenance Monitor for the soft
charge bypass relay.
See U4-06 to check when the bypass relay may need to be
replaced.

Default: 0%
Min.: 0%
Max.: 150%

o4-11

(510H)

U2, U3 Initialization

Fault Data Init
0: No Reset
1: Reset

0: U2-†† and U3-†† monitor data is not reset when the
regenerative unit is initialized (A1-03).
1: U2-†† and U3-†† monitor data is reset when the
regenerative unit is initialized (A1-03).

Default: 0
Min.: 0
Max.: 1

No.

(Address

Hex)

Name

LCD Display

Description

Values

TOEP_C710656_08B_1_0.book 167 ページ 2015年2月5日 木曜日 午前10時7分
