3.10 Control I/O Connections
YASKAWA ELECTRIC TOEP C710656 08B YASKAWA Power Regenerative Unit - R1000 Instruction Manual
65
El
ec
tr
ical
I
n
st
al
lat
ion
3
◆ Connect to a PC
This regenerative unit is equipped with a USB port (type-B).
The regenerative unit can connect to a USB port on a PC using a USB 2.0, AB-type cable (sold separately). After
connecting the regenerative unit to a PC, Yaskawa DriveWizard Industrial software can be used to monitor regenerative
unit performance and manage parameter settings. Contact Yaskawa for more information on DriveWizard Industrial.
Figure 3.27
Figure 3.30 Connecting to a PC (USB)
PC
USB Cable
(Type-AB)
(Type-B)
(Type-A)
