27
Table 17 Tabs on the device configuration information management page and functions provided
Tab Description
Label A label represents a configuration file of a device. .
Running Config
Allows you to perform operations on running configuration files of different
versions.
Startup Config
Allows you to view, back up, and delete the current startup configuration file of a
device.
The functions are the similar to those for management of running configuration
files.
Draft Allows you to manage drafts for a device.
Label
A label is used to indicate the backup running and/or startup configuration files of a device.
On the device configuration management list, you can click the icon in the Management column of a
device to bring up the configuration information management interface of the device, as shown in Figure
23 .
The Label tab allows you to:
• Add and delete labels.
• View the information of the backup configuration file, such as version number and backup time. A
backup file is uniquely identified by a version number assigned by the system.
• Compare two configuration files to find the differences.
• Click the restoration icon to set the startup configuration file and/or running configuration file of a
label as the startup configuration file and/or running configuration file for the device.
Table 18 Fields of the configuration label list
Field Description
Label Label of a startup configuration file and/or running configuration file.
Running Config Version number of the running configuration file associated with the label.
Backup Time Time when the running configuration file is backed up.
Compare
Allows you to compare two configuration files including the drafts to find the
differences.
Follow these steps:
1. Click the icon of a file and select Compare as Left from the menu to place the
file on the left side of the comparison page.
2. Click the icon of another file and select Compare To to place the file on
the right side of the comparison page, as shown in Figure 24 .
IMPORTANT:
The running configuration file does not support the xml format.
Startup Config Version number of the startup configuration file associated with the label.
Backup Time Time when the startup configuration file is backed up.
