YASKAWA TM.iQp.02 iQpump Drive Programming Manual 91
■
Broadcast Data
The following table shows the broadcast data. Broadcast Data Can Be Written (fuNction Code 06H/10H) only.
Table 24 Broadcast Data
■
Enter Command
When writing parameters to the iQpump drive from the PLC using Modbus communication, the parameters are temporarily stored in the
constant data area in the Drive. To enable these parameters in the parameter data area, use the Enter command.
There are two types of Enter commands:
1. Enter commands that enable parameter data in RAM
2. Enter commands that write data to EEPROM (non-volatile memory) in the iQpump drive at the same time as enabling data in RAM.
The following table shows the Enter command data. Enter command data can only be written.
The Enter command is enabled by writing 0 to register number 0900H or 0901H.
Table 25 Enter Command
Important: The maximum number of times you can write to EEPROM using the iQpump drive is 100,000. Do not frequently execute
Enter commands (0900H) written to EEPROM.
The Enter command registers are write-only. Consequently, if reading these registers, the register address will become invalid (Error
code: 02H).
Register Address Contents
0001H
Operation signal
Bit 0 Run forward 1: Run 0: Stop
Bit 1 Reverse operation command 1: Run 0: Stop
Bits 2 and 3 Not used
Bit 4 External error (1: Fault set using H1-01)
Bit 5 Error (Fault 1: Reset commandset using H1-02)
Bits 6 to B Not used
Bit C Multi-function digital input terminal S5 input
Bit D Multi-function digital input terminal S6 input
Bit E Multi-function digital input terminal S7 input
Bit F Not used.
0002H Frequency reference 30000/100%
Note: Bit signals not defined in the broadcast operation signals use local node data signals continuously.
Register No. Contents
0900H Write parameter data to EEPROM
0910H Parameter data is not written to EEPROM, but refreshed in RAM only.
