9469300990 Rev B 371
Fault
Code String Description
262 SD 5V BUFFR TEST Internal ECU fault.
263 SD TE BUFFR TEST Internal ECU fault.
264 SD BANK 1 TEST Internal ECU fault.
265 SD BANK 2 TEST Internal ECU fault.
266 SD SPD DEMAND AN Analog speed demand defect.
267 SD SPDMTEST BNCH Short circuit, cable breakage.
268 SD SPINUT Analog spinning value defect.
269 SD LOAD ANLG FLT Filtered analog load pulse signal not available.
270 SD FREQUENCY INPUT Frequency input defect.
271 SD T EXTERN 1 Missing data CAN.
272 SD T EXTERN 2 Missing data CAN.
273 SD P EXTERN 1 Missing data CAN.
274 SD P EXTERN 2 Missing data CAN.
275 SD EXT CLNT LVL Missing data CAN.
276 SD INTERCLER LVL Missing data CAN.
277 SD BIN EXT3 Missing data CAN.
278 SD BIN EXT4 Missing data CAN.
279 SD CANRES TRIPFL Missing data CAN.
280 SD CAN ALRM RST Missing data CAN.
281 SD ADTEST1 SPPLY Internal ECU fault.
282 SD ADTEST 2 SPPLY Internal ECU fault.
283 SD ADTEST3 SPPLY Internal ECU fault.
284 SD CAN LAMP TEST Missing data CAN.
285 SD CAN IDLE RQ SR Missing data CAN.
286 SD CAN IDLE REQ Missing data CAN.
287 SD CAN IDLE REQ Missing data CAN.
288 SD CAN TRBOSW LCK Missing data CAN.
301 TIMING CYLNDR A1 Error in timing of injector cylinder A1: timing value too low/high.
302 TIMING CYLNDR A2 Error in timing of injector cylinder A2: timing value too low/high.
303 TIMING CYLNDR A3 Error in timing of injector cylinder A3: timing value too low/high.
304 TIMING CYLNDR A4 Error in timing of injector cylinder A4: timing value too low/high.
305 TIMING CYLNDR A5 Error in timing of injector cylinder A5: timing value too low/high.
306 TIMING CYLNDR A6 Error in timing of injector cylinder A6: timing value too low/high.
307 TIMING CYLNDR A7 Error in timing of injector cylinder A7: timing value too low/high.
308 TIMING CYLNDR A8 Error in timing of injector cylinder A8: timing value too low/high.
309 TIMING CYLNDR A9 Error in timing of injector cylinder A9: timing value too low/high.
310 TIMING CYLNDR A10 Error in timing of injector cylinder A10: timing value too low/high.
311 TIMING CYLNDR B1 Error in timing of injector cylinder B1: timing value too low/high.
312 TIMING CYLNDR B2 Error in timing of injector cylinder B2: timing value too low/high.
313 TIMING CYLNDR B3 Error in timing of injector cylinder B3: timing value too low/high.
314 TIMING CYLNDR B4 Error in timing of injector cylinder B4: timing value too low/high.
315 TIMING CYLNDR B5 Error in timing of injector cylinder B5: timing value too low/high.
DGC-2020HD MTU Fault Codes
