SPN
FMI
String Displayed
Description
2791
3
EGRVlv Pos In Vlt HI
Exhaust Gas Recirculation Valve Position Input Voltage (High)
2791
4
EGRVlv Pos In Vlt LO
Exhaust Gas Recirculation Valve Position Input Voltage (Low)
2791
13
EGR Vlv Control ERR
Exhaust Gas Recirculation Valve Control Error
2791
31
EGR Valve Cal ERR
Exhaust Gas Recirculation Valve Calibration Error
2791
#
EGR VALVE CONTROL
Caption String for EGR Valve Control
2795
7
Trbo Act Pos MSMATCH
Turbo Actuator Position Mismatch
3380
#
Field Voltage
Generator Field Voltage
3381
#
Field Current
Generator Field Current
3719
0
DPF SOOT LVL EXT HI
String for Diagnostic Trouble Code Indicating Diesel Particulate
Filter Soot Level High - Most Severe Level
3719
15
DPF SOOT LVL HI
String for Diagnostic Trouble Code Indicating Diesel Particulate
Filter Soot Level High - Least Severe Level
3719
16
DPF SOOT LVL MOD HI
String for Diagnostic Trouble Code Indicating Diesel Particulate
Filter Soot Level High - Moderately Severe Level
520837
1
STARTER SPEED LO LO
Starter Speed is below the LOW LOW threshold
520838
1
RUN UP SPEED LO LO
Run Up Speed is below the LOW LOW threshold
522192
12
MTU ENGINE BAD
Component failure of the MTU engine control ECU
523212
#
ENGPRT CAN MSG
Caption String for CANBus Message
523216
#
PREHTENCMD CAN MSG
Caption String for CANBus Message
523218
#
RxCCVS CAN MSG
Caption String for CANBus Message
523222
#
TC01 CAN MSG
Caption String for CANBus Message
523238
#
SWTOUT CAN MSG
Caption String for CANBus Message
523239
#
DECV1 CAN MSG
Caption String for CANBus Message
523240
#
FUNMODCTL CAN MSG
Caption String for CANBus Message
523350
#
CYL BANK 1 INJECTORS
Caption String for Cylinder Bank 1 Injectors
523351
#
CYL BANK 1 INJECTORS
Caption String for Cylinder Bank 1 Injectors
523352
#
CYL BANK 2 INJECTORS
Caption String for Cylinder Bank 2 Injectors
523353
#
CYL BANK 2 INJECTORS
Caption String for Cylinder Bank 2 Injectors
523354
#
ECU ERROR
String for Diagnostic Trouble Code Indicating ECU Error
523355
#
ECU ERROR
String for Diagnostic Trouble Code Indicating ECU Error
523370
#
RAIL PRESSURE
Caption String for Rail Pressure
523420
#
ECU ERROR
String for Diagnostic Trouble Code Indicating ECU Error
523450
#
MULTI STATE SWITCH 1
Caption String for Multi State Switch 1
523451
#
MULTI STATE SWITCH 2
Caption String for Multi State Switch 2
523452
#
MULTI STATE SWITCH 3
Caption String for Multi State Switch 3
523470
#
RAIL PRESSURE LMT VLV
Caption String for Rail Pressure Limit Valve
523490
#
ECU ERROR
String for Diagnostic Trouble Code Indicating ECU Error
523500
#
CAN MSG TIMEOUT
Caption String indicating Can Message Timeout has occurred
523550
#
ECU ERROR
String for Diagnostic Trouble Code Indicating ECU Error
523561
#
INJECTN PERIOD CYL 1
Caption String for Single Cylinder Injection Period
523562
#
INJECTN PERIOD CYL 2
Caption String for Single Cylinder Injection Period
523563
#
INJECTN PERIOD CYL 3
Caption String for Single Cylinder Injection Period
523564
#
INJECTN PERIOD CYL 4
Caption String for Single Cylinder Injection Period
523565
#
INJECTN PERIOD CYL 5
Caption String for Single Cylinder Injection Period
