Issue 10/06

3 Functions

MICROMASTER 440 Operating Instructions

6SE6400-5AW00-0BP0

103

3.5.7.8

Motor potentiometer (MOP)

P1031 =...

Setpoint memory of the MOP
Saves last motor potentiometer setpoint (MOP) that was active before OFF command or
power down.
0 MOP setpoint will not be stored
1 MOP setpoint will be stored (P1040 is updated)

P1032 =...

Inhibit negative MOP setpoints

0 Neg. MOP setpoint is allowed

1 Neg. MOP setpoint inhibited

P1040 =... Setpoint of the MOP

Determines setpoint for motor potentiometer control.

MOP ramp-up and ramp-down times are defined by the parameters P1120 and P1121.

Selection

DIN

BOP

UP button

USS control word

r2032 Bit13

USS control word

r2032 Bit14

or

P0702 = 13

(DIN2)

P0703 = 14

(DIN3)

P0719 = 0, P0700 = 1, P1000 = 1

MOP up

MOP down

P0719 = 1, P0700 = 2

or

P0719 = 0, P0700 = 2, P1000 = 1

P0719 = 11

or

P0719 = 0, P0700 = 4, P1000 = 1

P0719 = 41

DOWN button

Possible parameter settings for the selection of MOP:

USS on
BOP link

USS control word

r2036 Bit13

USS control word

r2036 Bit14

or

P0719 = 0, P0700 = 5, P1000 = 1

P0719 = 51

USS on
COM link

CB control word

r2090 Bit13

r2090 Bit14

or

P0719 = 0, P0700 = 6, P1000 = 1

P0719 = 61

CB

CB control word

0

1

5.00 Hz
