3 Functions
Issue 10/06
MICROMASTER 440 Operating Instructions
190
6SE6400-5AW00-0BP0
Table 3-29
Examples for settings of parameter P0810
Parameter setting
Command source
P0810 = 722.2 requires P0703 = 99
Digital input 3
P0810 = 2032.15
USS at the BOP link
P0810 = 2036.15
USS at the COM link
P0810 = 2090.15
CB at the COM link
Table 3-30
Possible settings for parameters P0700 and P1000
Valu
e
Command source (P0700)
Valu
e
Setpoint source (P1000)
1 BOP
(keyboard)
1
MOP
setpoint
2 Terminal
strip
2
Analog
setpoint
4
USS at the BOP link
3
Fixed
frequency
5
USS at the COM link
4
USS at the BOP link
6
CB at the COM link
5
USS at the COM link
6
CB at the COM link
7
Analog setpoint 2
10 No main setpoint + MOP setpoint
...
77 Analog setpoint 2 + analog setpoint 2
