Issue 10/06 2 Installation
MICROMASTER 440 Operating Instructions
6SE6400-5AW00-0BP0 27
Frame Sizes A to F
160 mm
6.30"
55 mm
2.2"
Ø 4.5 mm
0.17"
Ø 4.8 mm
0.19"
174 mm
6.85"
138 mm
5.43"
Ø 5.5 mm
0.22"
204 mm
8.03"
174 mm
6.85"
Frame Size A
Frame Size D Frame Size E Frame Size F
Frame Size B Frame Size C
Ø 17.5 mm
0.68"
486 mm
19.13"
235 mm
9.25"
616.4 mm
24.27"
810 mm
31.89"
with
filter
1110 mm
43.70"
Ø 17.5 mm
0.68" Ø 15 mm
0.59"
235 mm
9.25"
300 mm
11.81"
Fig. 2-4 Drill pattern for MICROMASTER 440
