2 Installation Issue 10/06
MICROMASTER 440 Operating Instructions
30 6SE6400-5AW00-0BP0
Table 2-1 Dimensions and Torques of MICROMASTER 440
Frame-Size Overall Dimensions Fixing Method Tightening Torque
mm 73 x 173 x 149
A
Width x
Height x
Depth
inch 2,87 x 6,81 x 5,87
2 M4 Bolts
4 M4 Nuts
4 M4 Washers or fitting on a
standard
rail
2,5 Nm
with washers fitted
mm 149 x 202 x 172
B
Width x
Height x
Depth
inch 5,87 x 7,95 x 6,77
4 M4 Bolts
4 M4 Nuts
4 M4 Washers
2,5 Nm
with washers fitted
mm 185 x 245 x 195
C
Width x
Height x
Depth
inch 7,28 x 9,65 x 7,68
4 M5 Bolts
4 M5 Nuts
4 M5 Washers
2,5 Nm
with washers fitted
mm 275 x 520 x 245
D
Width x
Height x
Depth
inch 10,82 x 20,47 x 9,65
4 M8 Bolts
4 M8 Nuts
4 M8 Washers
3,0 Nm
with washers fitted
mm 275 x 650 x 245
E
Width x
Height x
Depth
inch 10,82 x 25,59 x 9,65
4 M8 Bolts
4 M8 Nuts
4 M8 Washers
3,0 Nm
with washers fitted
mm
350 x 850 mm x 320
height with filter 1150
F
Width x
Height x
Depth
inch
13,78 x 33,46 x 12,60
height with filter 45,28
4 M8 Bolts
4 M8 Nuts
4 M8 Washers
3,0 Nm
with washers fitted
mm 326 x 1400 x 356
FX
Width x
Height x
Depth
inch 12,80 x 55,12 x 12,83
6 M8 Bolts
6 M8 Nuts
6 M8 Washers
13 Nm +30 %
with washers fitted
mm 326 x 1533 x 545
GX
Width x
Height x
Depth
inch 12,80 x 60,35 x 21,46
6 M8 Bolts
6 M8 Nuts
6 M8 Washers
13 Nm +30 %
with washers fitted
