A.3 Heat Loss Data
YASKAWA ELECTRIC TOEP C710656 07C YASKAWA Power Regenerative Converter - D1000 Instruction Manual 177
S
p
ec
ifi
ca
tio
n
s
A
A.3 Heat Loss Data
Table A.3 Heat Loss
Model Rated Amps (A) Heatsink Loss (W) Interior Unit Loss (W) Total Loss (W)
200 V Class
2A0005 15 93 38 131
2A0010 30 167 57 224
2A0020 61 319 101 420
2A0030 91 380 134 514
2A0050 152 666 245 911
2A0065 197 1193 464 1657
2A0090 273 1616 619 2235
2A0130 394 1918 776 2694
400 V Class
4A0005 8 83 37 120
4A0010 15 158 58 216
4A0020 30 314 103 417
4A0030 45 263 109 372
4A0040 61 647 201 848
4A0060 91 1092 334 1426
4A0100 152 1303 467 1770
4A0130 197 1969 695 2664
4A0185 280 2864 997 3861
4A0270 409 2477 1323 3799
4A0370 561 3705 1852 5557
4A0630 955 6103 3098 9201
