9.1 List of Parameters
9-41
9
Ap
pend
ix
88
PnB10
4
Monitor Selection 2
–
–
0
Immedi-
ately
Command
Related
Parameters
0000H
to
000FH
Same as Monitor Selection 1.
89
PnB12
4
Monitor Selection for SEL_MON1
(CMN1)
0 to 6
–
0
Immedi-
ately
0000H
TPOS (Target position in the reference coordinates)
0001H
IPOS (Reference position in the reference coordinates)
0002H
POS_OFSET (Offset value set in the set coordinates command
(POS_SET))
0003H
TSPD (Target speed)
0004H
SPD_LIM (Speed limit value)
0005H
TRQ_LIM (Force limit value)
0006H
SV_STAT
Monitor
Byte 1: Current communications phase
00H: Phase 0
01H: Phase 1
02H: Phase 2
03H: Phase 3
Byte 2: Current control mode
00H: Position control mode
01H: Speed control mode
02H: Force control mode
Byte 3: Reserved
Byte 4: Expansion signal monitor
(cont’d)
Parameter
No.
Size
Name
Setting Range
Units
[Resolution]
Factory
Setting
When
Enabled
Classifica-
tion
Bit
Name
Contents
Value
Setting
Bit 0 LT_RDY1
Processing status
for latch detection
specified by
SVCMD_CTRL,
LT_REQ1
0
Latch
detection not
processed
1
During latch
detection
processing
Bit 1 LT_RDY1
Processing status
for latch detection
specified by
SVCMD_CTRL,
LT_REQ2
0
Latch
detection not
processed
1
During latch
detection
processing
Bit 2,
Bit 3 LT_SEL1R
Latch signal
0
Phase C
1
External
input signal 1
2
External
input signal 2
3
External
input signal 3
Bit 4,
Bit 5 LT_SEL2R
Latch signal
0
Phase C
1
External
input signal 1
2
External
input signal 2
3
External
input signal 3
Bit 6 Reserved (0)
