The Project Explorer
MotionWorks+™
18
Pn408
0
0
1
Torque Function Switches. See section 6.1.6 in SGDH manual.
Pn409
2000
50
2000
Notch Filter Frequency in Hz. Only effective when the SGDH is
used in torque mode. See section 6.1.6 in SGDH manual.
Pn500
7
0
250
Positioning Completed Width in pulses. It is recommended to
use sPosition_CompletionWindow instead. See section 5.5.3
of SGDH manual.
Pn501
10
0
10000 Zero Clamp Level in rpm. See section 5.4.3 in SGDH manual.
Pn502
20
1
10000 Rotation Detection Level in rpm. See section 5.5.5 of SGDH
manual.
Pn503
10
0
100
Speed Coincidence Signal Output Width in rpm. See section
5.5.4 of SGDH manual.
Pn504
7
1
250
NEAR Signal Width in pulses. See section 5.5.8 of SGDH man-
ual.
Pn505
1024
1
32767 Overflow Level in 256 pulses. This parameter is not applicable
when the SGDH is used with the MP940. See section 6.2.1 of
SGDH manual.
Pn506
0
0
50
Brake Reference Servo OFF Delay Time in 10ms. See section
5.4.4 of SGDH manual.
Pn507
100
0
10000 Brake Reference Output Speed Level in rpm. See section 5.4.4
of SGDH manual.
Pn508
50
10
100
Timing for Brake Reference Output during Motor Operation in
10ms. See section 5.4.4 of SGDH manual.
Pn509
20
20
1000
Momentary Hold Time in ms. See section 5.4.9 of SGDH man-
ual.
Pn50A
2881
0
FFFF
Input Signal Selections 1. See section 5.3.3 of SGDH manual.
Pn50B
8883
0
FFFF
Input Signal Selections 2. See section 5.3.3 of SGDH manual.
Pn50C
8888
0
FFFF
Input Signal Selections 3. See section 5.3.3 of SGDH manual.
Pn50D
8888
0
FFFF
Input Signal Selections 4. See section 5.3.3 of SGDH manual.
Pn50E
3211
0
3333
Output Signal Selections 1. See section 5.3.4 of SGDH man-
ual.
Pn50F
0
0
3333
Output Signal Selections 2. See section 5.3.4 of SGDH manual.
Pn510
0
0
33
Output Signal Selections 3. See section 5.3.4 of SGDH man-
ual.
Pn511
6541
0
FFFF
Input Signal Selections 5. See section 5.3.3 of SGDH manual.
Pn512
0
0
111
Output Signal Reversal Settings. See section 5.3.4 of SGDH
manual.
Pn600
0
0
9000
Regenerative Resistor Capacity in watts. See section 5.6.1 of
SGDH manual.
Property
Default
Min
Max
Details (online Help message)
