ATEIS - IDA8 68
© 2012 ATEÏS
Contact Output
Contact Form Maximum Unit
Carry Current 1.0 ADC
Maximum Voltage 100 VDC
Electrical Life 1 x 10^8 (Ref 10VDC, 10mA) -
Working Temperature:
0°C ~ 40°C
4.1.3.5 3rd Party Control
The following table lists 3rd Party Control protocols which are IDA8C Supported.
Protocol
Interface
Function
Connection Settings
Ateis 3rd
Party
Protocol
Ethernet(UDP)
UDP Port =
19761
Read/Write value of parameters.
Stepped adjustment for parameters.
Modbus PDC(RS485) PDC Port 1~ 2
Level control
Paging
Read Monitoring Status
Read Evacuation Status
Play Message
Logic I/O Control
4.1.3.6 Peripherals
Following table is the peripherals supported by IDA8SL:
Device Connection Max. Num Function
Fireman MIC Fireman MIC 1 Paging where operator is close to the IDA8C.
