Parameter Value
Alarm 1 setpoint
10
Alarm 1 type
PV 1 dev NC
Alarm 1 hysteresis
1
Alarm 1 Smart Alarm
Disabled
Alarm 1 ON delay time
0
Alarm 2 setpoint
15
Alarm 2 type
PV 2 dev NC
Alarm 2 hysteresis
1
Alarm 2 Smart Alarm
Disabled
Alarm 2 ON delay time
0
Alarm 3 setpoint
1400
Alarm 3 type
PV 2 proc high
Alarm 3 hysteresis
1
Alarm 3 Smart Alarm
Disabled
Alarm 3 ON delay time
0
%C Dual Temp:
Parameter Value
Alarm 1 setpoint
10
Alarm 1 type
PV 1 band NC
Alarm 1 hysteresis
1
Alarm 1 Smart Alarm
Disabled
Alarm 1 ON delay time
0
Alarm 2 setpoint
15
Alarm 2 type
PV 2 band NC
Alarm 2 hysteresis
1
Alarm 2 Smart Alarm
Disabled
Alarm 2 ON delay time
0
Alarm 3 setpoint
1400
Alarm 3 type
PV 2 proc high
Alarm 3 hysteresis
1
Alarm 3 Smart Alarm
Disabled
Alarm 3 ON delay time
0
Setpoint:
This value is the setpoint for the alarm. Clicking on this value will display an input box from
which the user can select a new value. The range is from –9999.00 to 9999.00.
Alarm Type:
This value is the type of alarms used. Clicking on this value will display an input box with two
(2) drop-down lists from which the user can select a new value.
The values in the first (top) list box are:
PV 1 Value
