CDM-625A Advanced Satellite Modem MN-CDM625A
Serial-based Remote Product Management Revision 3
8–7
8.5 Remote Commands and Queries
8.5.1 Table Indexes
Notes:
1) Index Columns – Where Column ‘C’=Command, and Column ‘Q’=Query, columns marked ‘X’ designate the instruction code as
Command only, Query only, or Command or Query. Where CODE=XXX, this indicates a priority command.
2) In the tables that follow, the following codes are used in the ‘Response to Command’ column (per Sect. 8.5.5):
= Message ok # Message ok, but unit is not in Remote mode.
? Received ok, but invalid arguments were found. ~ Time out of a pass-through message, either to via EDMAC or to a local ODU.
^ Message ok, but unit is in Ethernet mode.
Sect. 8.5.2 Tx Parameters
CODE C Q PAGE CODE C Q PAGE CODE C Q PAGE CODE C Q PAGE CODE C Q PAGE
APP X X 8-15 TBA X X 8-17 TFQ X X 8-13 TMX X X 8-13 TTF X 8-17
AUP X X 8-15 TCI X X 8-16 TFT X X 8-11 TPL X X 8-14 TVL X X 8-16
DTS X X 8-17 TCK X X 8-16 TIR X 8-17 TRS X X 8-14 TXA X X 8-15
DTY X X 8-17 TCR X X 8-11 TIT X X 8-10 TSC X X 8-14 TXO X X 8-15
TDI X X 8-13 TLO X X 8-17 TSI X X 8-14
PLI X 8-16 TDR X X 8-13 TMD X X 8-11 TSR X X 8-13
TET X X 8-17 TMI X 8-18 TTA X X 8-16
REB X 8-16 TFM X X 8-10 TMR X X 8-14 TTC X X 8-17
Sect. 8.5.3 Rx Parameters
CODE C Q PAGE CODE C Q PAGE CODE C Q PAGE CODE C Q PAGE CODE C Q PAGE
EBA X X 8-24 RCI X X 8-24 RFM X X 8-19 RMR X X 8-23 RTF X 8-25
ITS X X 8-25 RCK X X 8-24 RFQ X X 8-22 RMX X X 8-22 RVL X X 8-24
ITY X X 8-24 RCR X X 8-20 RFT X X 8-20 RRS X X 8-23
RDI X X5 8-22 RIR X 8-25 RSI X X 8-23
RDR X X 8-22 RIT X X 8-19 RSR X X 8-22
RBA X X 8-25 RDS X X 8-23 RLO X X 8-25 RSW X X 8-23
RBS X X 8-24 REE X X 8-25 RMD X X 8-20 RTC X X 8-24
RCB X 8-25 RET X X 8-25 RMI X 8-26 RTE X X 8-24
