Chapter 6: Module/Unit Replacement
PC NC Maintenance Manual
6-3
hard disk drive assembly cover by loosening the four mounting
lock nuts.
4.
Loosen the four top/bottom-mounting screws from the hard disk
drive assembly mounting plate and remove the hard disk drive
assembly.
Install a hard disk drive unit by following the steps below.
1.
Install the new hard disk drive assembly and tighten the four top/
bottom-mounting screws.
2.
Attach the hard disk drive assembly cover and tighten the four
mounting lock nuts.
3.
Attach the door to the CPU rack by inserting the side-pins into the
door hinges.
4.
Plug hard disk drive data (HD DATA) and power (HD PWR)
cables into their original locations.
5.
Close the door and tighten the top/bottom thumbscrews.
6.
Return the power supply switch of the CPU rack to the “I” posi-
tion and power up to restart the control unit.
7.
Change the Windows NT serial number.
8.
Follow the HD data set-up procedures.
Following replacement of the hard disk drive, verify functions as follows.
1.
Verify that the hard disk drive unit type is displayed correctly on
the BIOS screen at boot-up.
2.
Verify that Windows NT boots up correctly.
3.
Verify that the NC operates normally after the SERVO ON switch
is pressed and that no alarms show on the MMI screen.
