OB (Output Bit)
[I/O]
DESCRIPTION:
The OB n, logical expression command defines output bit n = 1 through 8 as either 0 or 1 depending on the
result from the logical expression. Any non-zero value of the expression results in a one on the output.
ARGUMENTS: OB n, expression
where
n is 1 through 8 denoting output bit
expression is any valid logical expression, variable or array element.
USAGE:
EXAMPLES:
While Moving
Yes
Default Value
---
In a Program
Yes
Default Format
---
Command Line
Yes
Can be Interrogated
No
Used as an Operand
No
OB 1, POS 1
If POS1 is non-zero, Bit 1 is high. If POS1 is zero, Bit 1 is low
OB 2, (@IN[1]&@IN[2])
If Input 1 and Input 2 are both high, then Output 2 is set high
OB 3, COUNT[1]
If the element 1 in the array is zero, clear bit 3, otherwise set bit 3
OB N, COUNT[1]
If element 1 in the array is zero, clear bit N
