UTC (Coordinated Universal Time)

SG-UTC=M,R,B

M (Offset from UTC in Minutes) = -720 to 840

R (Reference Time) = 0 (Local) or 1 (UTC)

B (Bias: amount of minutes to adjust DST) = 1 to 300

Example: SG-UTC=0,0,60 for UTC offset of 0 minutes, local reference for the DST change, and

adjustment amount of 60 minutes

The RG-DST command reports start and stop times and dates for daylight saving time referenced to local

time. Refer to Section 11, ASCII Command Interface, for a list of all ASCII commands.

General Status Reporting

BE1-851 relays have extensive capabilities for reporting relay status. This is important for determining the

health and status of the system for diagnostics and troubleshooting. Throughout this manual, reference is

made to the RG-STAT (report general – status) report and the appropriate HMI screens for determining

the status of various functions.

General Status Report

A General Status Report is available through the communication ports using the RG-STAT command.

This report lists all of the information required to determine the status of the relay. An example of a typical

general status report follows. In the explanation of what each line represents, cross-references are made

to the corresponding HMI screens that contain that data.

>RG-STAT
INPUT(1234) STATUS : 0000

OUTPUT(A12345) STATUS : 000000

CO-OUT(A12345) STATUS : LLLLLL

CO-43/143/243/343 STATUS : 0000

CO-101(101SC) STATUS : AFTER CLOSE(1)

CO-GROUP STATUS : L

ACTIVE LOGIC STATUS : USER

LOGIC VAR(00-31) STATUS : 00000000 00000000 00000000 00000000

LOGIC VAR(32-63) STATUS : 00000000 00000000 00000010 00011000

RECLOSER(79) STATUS : OFF

ACTIVE GROUP STATUS : 0

BREAKER(52) STATUS : CLOSED

DIAG/ALARM STATUS : 0 RELAY, 0 LOGIC, 0 MAJOR, 0 MINOR

Input (1234)

This line reports the status of contact sensing inputs IN1, IN2, IN3, and IN4. Input information is available

at HMI Screen 1.5.1. 0 indicates a de-energized input and 1 indicates an energized input. See Section 3,

Input and Output Functions, for more information about contact sensing input operation.

Output (A12345)

Current output contact status is reported on this line. This information is also available at HMI Screen

1.5.2. 0 indicates a de-energized output and 1 indicates an energized output. More information about

output contact operation is available in Section 3, Input and Output Functions.

CO-OUT (A12345)

This line reports the logic override of the output contacts. Logic override status is reported at HMI Screen

1.5.3. Section 3, Input and Output Functions, provides more information about overriding output contacts.

CO-43/143/243/343

Virtual switch function status is reported on this line. This information is also available at HMI Screen

1.5.4. See Section 4, Protection and Control, for more information about virtual switch operation.

6-4

BE1-851 Reporting and Alarms

9289900990 Rev R
