The following feature measurements are supported by the QC5200:
• Points • Slots • Blobs
• Lines • Distances
• Arcs • Angles
• Circles • Profiles
Features can be probed manually or automatically as part of a program using video edge detection in
systems that include CNC stages.
NOTE
Manual probing is discussed in Chapter 4: Probes
Chapter 4: Probes. Automatic probing is discussed in
Chapter 8: Programming
Chapter 8: Programming.
Probing and Measuring Features
