Register Map
An Avalon-MM master peripheral controls and communicates with the SPI core via the six 32-bit
registers, shown in below in the Register Map for SPI Master Device figure. The table assumes an n-bit
data width for
rxdata
and
txdata
.
Table 10-5: Register Map for SPI Master Device
Interna
l
Addres
s
Register Name Type
[R/W]
32..11 10 9 8 7 6 5 4 3 2 1 0
0
rxdata
(1) R
RXDATA
(n-1..0)
1
txdata
(1) W
TXDATA
(n-1..0)
2
status
(2) R/W
E RRDY TRDY TMT TOE ROE
3
control
R/W
SSO
(3)
IE IRRDY ITRDY ITOE IROE
4 Reserved —
5
slaveselect
(3) R/W Slave Select Mask
Table 10-5 :
1. Bits 31 to n are undefined when n is less than 32.
2. A write operation to the
status
register clears the
ROE
,
TOE
, and
E
bits.
3. Present only in master mode.
Reading undefined bits returns an undefined value. Writing to undefined bits has no effect.
rxdata Register
A master peripheral reads received data from the
rxdata
register. When the receive shift register receives
a full n bits of data, the
status
register's
RRDY
bit is set to 1 and the data is transferred into the
rxdata
register. Reading the
rxdata
register clears the
RRDY
bit. Writing to the
rxdata
register has no effect.
New data is always transferred into the
rxdata
register, whether or not the previous data was retrieved. If
RRDY
is 1 when data is transferred into the
rxdata
register (that is, the previous data was not retrieved), a
receive-overrun error occurs and the
status
register's
ROE
bit is set to 1. In this case, the contents of
rxdata
are undefined.
txdata Register
A master peripheral writes data to be transmitted into the
txdata
register. When the
status
register's
TRDY
bit is 1, it indicates that the
txdata
register is ready for new data. The
TRDY
bit is set to 0 whenever
the
txdata
register is written. The
TRDY
bit is set to 1 after data is transferred from the
txdata
register
into the transmitter shift register, which readies the
txdata
holding register to receive new data.
A master peripheral should not write to the
txdata
register until the transmitter is ready for new data. If
TRDY
is 0 and a master peripheral writes new data to the
txdata
register, a transmit-overrun error occurs
and the
status
register's
TOE
bit is set to 1. In this case, the new data is ignored, and the content of
txdata
remains unchanged.
