2 internal audio, 1 media players, Internal audio – NewTek TriCaster 300 User Manual
Page 204: Media players
Page | 188
are shown in red in the VU meters, to caution you that overly high levels can result in clipping in
recordings.
Hint: An error message appears in the Status Bar above the main Program output monitor to
warn you if clipping occurs – see Section 6.5.1.
13.2 INTERNAL AUDIO
Besides external audio sources, sounds played from TriCaster’s internal storage volumes
(including removable media such as external hard drives or ‘thumb’ drives) via the Media Players
can be added to the output mix. Separate sub-panels are provided to control audio added to
TriCaster’s Program Output mix by the DDR and Sound media players.
Figure 181
13.2.1 MEDIA PLAYERS
Video and audio-only files in DDR playlists, along with audio files in the Stills player, may contain
one or more audio channels. At most, Media Players output the first four audio channels of
multiple channels – additional embedded streams are ignored.
