7-10
Field Description
Failed RTS Number of RTS failed during transmission
Successful RTS Number of RTS transmitted successfully
Failed ACK
Number of transmitted frames for which no acknowledgement is
received
Association Frames Number of association responses transmitted
Packet Count Statistics Based on Size
Number of frames counted based on the frame size. The frame size
falls in the following four ranges:
size < 128
128 < size < 512
512 < size < 1024
size > 1024
Packet Count Statistics Based on Rate
Numbers of frames counted separately based on their transmit
rates: 802.11a, 802.11b, or 802.11g. Only the numbers of frames
counted based on the data rates supported by the radio of the AP
are displayed. For example, if the radio supports 802.11a, the
number of 802.11a frames is displayed, and numbers of 802.11b
and 802.11g frames will not be displayed.
Packet Count Statistics Based on MCS
Rate
Numbers of frames counted separately based on their MCS rates.
If the device does not support 802.11n, this field will not be
displayed.
Received Frames Statistics Statistics of received frames
Total Frames Number of frames received
Unicast Frames Number of unicast frames received
Broadcast/Multicast Frames Number of broadcast or multicast frames received
Fragmented Frames Number of fragmented frames received
FCS Failures Number of frames dropped due to FCS failure
Authentication Frames Number of authentication requests received
Duplicate Frames Number of duplicate frames received
Decryption Errors Number of frames dropped due to decryption error
Association Frames Number of association requests received
Displaying AP Detailed Information
Select Summary > AP from the navigation tree to enter the AP page, click the Detail tab on the page,
and click the name of the specified AP to view the detailed information of an AP.
The detailed information of an AP is as shown in Figure 7-9 . For the description of the fields in the AP
detailed information, refer to Table 7-8 .
