Yaskawa iQpump Micro - Manual (Page 243)

No.
(Addr.
Hex)
Name LCD Display Description Values Page
F6-55
(03C6)
DeviceNet Baud Rate
Monitor
DN BAUD RATE
MEM
0: 125 kbps
1: 250 kbps
2: 500 kbps
Verifies the baud rate running on the network.
0: 125 kbps
1: 250 kbps
2: 500 kbps
Default: 0
Range: 0 to 2
–
F6-56
(03D7)
DeviceNet Speed
Scaling
DN Speed Scale
Sets the scaling factor for the speed monitor in DeviceNet. Default: 0
Min.: -15
Max.: 15
–
F6-57
(03D8)
DeviceNet Current
Scaling
DN Current Scale
Sets the scaling factor for the output current monitor in
DeviceNet.
Default: 0
Min.: -15
Max.: 15
–
F6-58
(03D9)
DeviceNet Torque
Scaling
DN Torque Scale
Sets the scaling factor for the torque monitor in DeviceNet. Default: 0
Min.: -15
Max.: 15
–
F6-59
(03DA)
DeviceNet Power
Scaling
DN Power Scale
Sets the scaling factor for the power monitor in DeviceNet. Default: 0
Min.: -15
Max.: 15
–
F6-60
(03DB)
DeviceNet Voltage
Scaling
DN Voltage Scale
Sets the scaling factor for the voltage monitor in DeviceNet. Default: 0
Min.: -15
Max.: 15
–
F6-61
(03DC)
DeviceNet Time
Scaling
DN Time Scale
Sets the scaling factor for the time monitor in DeviceNet. Default: 0
Min.: -15
Max.: 15
–
F6-62
(03DD)
DeviceNet Heartbeat
Interval
DN Heart Beat
Sets the heartbeat interval for DeviceNet communications. Default: 0
Min.: 0
Max.: 10
–
F6-63
(03DE)
DeviceNet Network
MAC ID
DN MAC ID MEM
Saves and monitors settings 0 to 63 of F6-50 (DeviceNet MAC
Address).
Default: 63
Min.: 0
Max.: 63
–
F6-64 to
F6-71
(03DF to
03C8)
Dynamic I/O Assembly
Parameters
–
Dynamic I/O Assembly Parameters
– –
F7-01 to
F7-42
(03E5 to
037E)
EtherNet/IP and
Modbus TCP/IP Option
Parameters
–
F7 parameters are reserved for use with SI-EN3/V and
SI-EM3/V options. Refer to the respective Option Manuals for
details.
– –
<1> Parameter setting value is not reset to the default value when the drive is initialized.
B.6 F: Options
YASKAWA TOEP YAIQPM 03B YASKAWA AC Drive - iQpump Micro User Manual 243
B
Parameter List
