YASNAC PC NC Operating Manual
Appendix 2: Alarm Tables
A2 - 8
alarm.1001
DNC DR line error has occurred.
alarm.1002
DNC packet length error has occurred.
alarm.1003
DNC 8251 error has occurred.
alarm.1004
DNC check sum error has occurred.
alarm.1005
DNC command error has occurred.
alarm.1006
DNC high-speed cutting mode error has occurred.
alarm.1007
DNC communication module diagnosis error has occurred.
alarm.1008
DNC CPU error has occurred.
alarm.1009
DNC 51 error has occurred.
alarm.1020
Start number of the battery backed-up memory storing the cell controller I/0 link information is outside the
allowable range.
alarm.1021
An interface error between the cell controller and COM in the cell controller system.
alarm.1041
Incorrect command has been made for the PLC control axis (X-axis).
alarm.1042
Incorrect command has been made for the PLC control axis (Y-axis).
alarm.1043
Incorrect command has been made for the PLC control axis (Z-axis).
alarm.1044
Incorrect command has been made for the PLC control axis (4th-axis).
alarm.1045
Incorrect command has been made for the PLC control axis (5th-axis).
alarm.1051
Axis has been changed while the control axis selected status signal is ON (X-axis).
alarm.1052
Axis has been changed while the control axis selected status signal is ON (Y-axis).
alarm.1053
Axis has been changed while the control axis selected status signal is ON (Z-axis).
alarm.1054
Axis has been changed while the control axis selected status signal is ON (4th-axis).
alarm.1055
Axis has been changed while the control axis selected status signal is ON (5th-axis).
alarm.1080
Execution of a program block has been stopped with the ERR 0 signal ON.
alarm.1090
Setting area total check error has occurred.
alarm.1091
Parameter area total check error has occurred.
alarm.1092
Battery backed-up memory area total check error has occurred.
alarm.1093
Offset and work coordinate system shift amount area total check error has occurred.
alarm.1094
Macro variable area total check error has occurred.
alarm.1095
Machining program area total check error has occurred.
alarm.1096
Tool life control data area total check error has occurred.
alarm.1098
The Fan is faulty. {Refer to A1-20}
alarm.1099
High temperature in the NC unit. {Refer to A1-20}
alarm.2001
Overtravel has occurred (X-axis).
Alarm No.
Description
