YASNAC PC NC Operating Manual Chapter 3: HMI Process Operation
3 - 17
• Press the Copy button.
• Touch the Search Up/Down text field to select it.
• Press the Paste button. The text from the program editor should now appear in the
Search text field.
Copying from one screen to another screen:
• Change to the Tools: Offsets screen.
• Select a cell in the offsets grid. The border of the cell should turn black, and the Copy
and Paste buttons should become enabled.
• Press the Copy button.
• Change to the Setup: Workshift screen.
• Select a cell in the workshifts grid. The border of the cell should turn black, and the Copy
and Paste buttons should become enabled.
• Press the Paste button. The number from the tool offsets grid should now appear in the
workshift grid. (To keep the original cell value, select another cell in the grid immediately
after the copy.)
Copying from a position display:
• Change to the Run: Proveout screen.
• Select a number field in one of the position displays (the position does not have to be edit-
able). The border of the number field in the position display is now black, and the Copy
button enables.
• Press the Copy button. The selected number field looks the same.
• Select the search text field below the Search Up button. Copy is now disabled, but
the Paste button becomes enabled.
• Press the Paste button. The number from the position display should now be displayed in
the search text field.
• Delete the pasted text to return to the previous state.
The Back arrow will jump to the last screen shown, up to a maximum of 100. It is dis-
abled if there is no previous screen.
The Forward arrow will go to the screen that is the next in the screen list. This is dis-
abled if the user has never used the back arrow.
Using the Backward and Forward buttons:
• Change to the Run: Production screen.
