YASNAC PC NC Operating Manual
APPENDIX 3: Parameter Tables
A3 - 38
Backlash
Address
Bit
Description
Register
Units
Minimum
Value
Maximum
Value
Long Description
pm1551
1st axis backlash compensation amount
0.1micron
0
32767
pm1552
2nd axis backlash compensation amount
0.1micron
0
32767
pm1553
3rd axis backlash compensation amount
0.1micron
0
32767
pm1554
4th axis backlash compensation amount
0.1micron
0
32767
pm1555
5th axis backlash compensation amount
0.1micron
0
32767
pm1711
1st axis backlash time constant
0.01msec
0
32767
pm1712
2nd axis backlash time constant
0.01msec
0
32767
pm1713
3rd axis backlash time constant
0.01msec
0
32767
pm1714
4th axis backlash time constant
0.01msec
0
32767
pm1715
5th axis backlash time constant
0.01msec
0
32767
pm2481
1st axis backlash compensation amount in
G01 mode
0.1micron
-32767
32767
pm2482
2nd axis backlash compensation amount in
G01 mode
0.1micron
-32767
32767
pm2483
3rd axis backlash compensation amount in
G01 mode
0.1micron
-32767
32767
pm2484
4th axis backlash compensation amount in
G01 mode
0.1micron
-32767
32767
pm2485
5th axis backlash compensation amount in
G01 mode
0.1micron
-32767
32767
pm2491
1st axis backlash compensation amount in
Handle
0.1micron
-32767
32767
pm2492
2nd axis backlash compensation amount in
Handle
0.1micron
-32767
32767
pm2493
3rd axis backlash compensation amount in
Handle
0.1micron
-32767
32767
pm2494
4th axis backlash compensation amount in
Handle
0.1micron
-32767
32767
pm2495
5th axis backlash compensation amount in
Handle
0.1micron
-32767
32767
