YASNAC PC NC Operating Manual
APPENDIX 3: Parameter Tables
A3 - 91
8415
5th axis, position gap distance limit when
power ON
0
32767
8471
1st axis (- to +) roundness irregularity Inte-
gral constant
msec
0
32767
8472
2nd axis (- to +) roundness irregularity Inte-
gral constant
msec
0
32767
8473
3rd axis (- to +) roundness irregularity Inte-
gral constant
msec
0
32767
8474
4th axis (- to +) roundness irregularity Inte-
gral constant
msec
0
32767
8475
5th axis (- to +) roundness irregularity Inte-
gral constant
msec
0
32767
8481
1st axis (- to +) roundness irregularity com-
pletion torque
0.01%
0
20000
8482
2nd axis (- to +) roundness irregularity com-
pletion torque
0.01%
0
20000
8483
3rd axis (- to +) roundness irregularity com-
pletion torque
0.01%
0
20000
8484
4th axis (- to +) roundness irregularity com-
pletion torque
0.01%
0
20000
8485
5th axis (- to +) roundness irregularity
0.01%
0
20000
8491
1st axis roundness irregularity Timing
parameter
0.01[1/S]
-32767
32767
8492
2nd axis roundness irregularity Timing
parameter
0.01[1/S]
-32767
32767
8493
3rd axis roundness irregularity Timing
parameter
0.01[1/S]
-32767
32767
8494
4th axis roundness irregularity Timing
parameter
0.01[1/S]
-32767
32767
8495
5th axis roundness irregularity Timing
parameter
0.01[1/S]
-32767
32767
8501
1st axis (+ to -) roundness irregularity Inte-
gral constant
msec
0
32767
8502
2nd axis (+ to -) roundness irregularity Inte-
gral constant
msec
0
32767
8503
3rd axis (+ to -) roundness irregularity Inte-
gral constant
msec
0
32767
8504
4th axis (+ to -) roundness irregularity Inte-
gral constant
msec
0
32767
8505
5th axis (+ to -) roundness irregularity Inte-
gral constant
msec
0
32767
8511
1st axis (+ to -) roundness irregularity com-
pletion torque
0.01%
0
20000
8512
2nd axis (+ to -) roundness irregularity com-
pletion torque
0.01%
0
20000
Address
Bit
Description
Register
Units
Minimum
Value
Maximum
Value
Long Description
