YASNAC PC NC Operating Manual
APPENDIX 3: Parameter Tables
A3 - 74
1602
3rd axis Speed loop integration time constant
0.01msec
26
32767
1603
3rd axis Second position loop gain Kp
0.01[1/S]
500
20000
1604
3rd axis Speed feed forward gain Kvfff
%
0
100
1605
3rd axis Second velocity loop gain Kv
0.1[1/S]
350
32767
1606
3rd axis First step axis torsion filter time
constant Tn
0.01msec
1
32767
1607
3rd axis Second step axis torsion filter time
constant Tn
0.01msec
1
32767
1608
3rd axis Third step axis torsion filter time
constant Tn
0.01msec
1
32767
1609
3rd axis Monitor board signal selection, mul-
tiplication
0
32767
1610
4th axis Position loop gain Kp
0.01[1/S]
500
20000
1611
4th axis Velocity loop gain Kv
0.1[1/S]
350
32767
1612
4th axis Speed loop integration time constant
Ti
0.01msec
26
32767
1613
4th axis Second position loop gain Kp
0.01[1/S]
500
20000
1614
4th axis Speed feed forward gain Kvfff
%
0
100
1615
4th axis Second velocity loop gain Kv
0.1[1/S]
350
32767
1616
4th axis First step axis torsion filter time con-
stant Tn
0.01msec
1
32767
1617
4th axis Second step axis torsion filter time
0.01msec
1
32767
1618
4th axis Third step axis torsion filter time
constant Tn
0.01msec
1
32767
1619
4th axis Monitor board signal selection, mul-
tiplication
0
32767
1620
5th axis Position loop gain Kp
0.01[1/S]
500
20000
1621
5th axis Velocity loop gain Kv
0.1[1/S]
350
32767
1622
5th axis Speed loop integration time constant
Ti
0.01msec
26
32767
1623
5th axis Second position loop gain Kp
0.01[1/S]
500
20000
1624
5th axis Speed feed forward gain Kvfff
%
0
100
1625
5th axis Second velocity loop gain Kv
0.1[1/S]
350
32767
1626
5th axis First step axis torsion filter time con-
stant Tn
0.01msec
1
32767
1627
5th axis Second step axis torsion filter time
constant Tn
0.01msec
1
32767
1628
5th axis Third step axis torsion filter time
constant Tn
0.01msec
1
32767
1629
5th axis Monitor board signal selection, mul-
tiplication
0
32767
1641
1st axis Variable in position check No1 area
0.001mm
0
32767
Address
Bit
Description
Register
Units
Minimum
Value
Maximum
Value
Long Description
