BIOS CONFIGURATION
101
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Ethernet Configuration
Ethernet Configuration
DHCP Function : Enable
Local IP Address : 192.168.001.100
HTTP Port Number : 80
Telent Port Number : 23
SMTP Port Number : 25
EtherNet Address : 00. 04. D9.7F .FF. FF
Local IP Address : 192.168.001.100
Edit The Local IP Address
92.168.001.100 1
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Ethernet Configuration
Ethernet Configuration
DHCP Function : Enable
Local IP Address : 192.168.001.100
HTTP Port Number : 80
Telent Port Number : 23
SMTP Port Number : 25
EtherNet Address : 00. 04. D9.7F .FF. FF
DHCP Function : Enable
Select DHCP Setting
Enabled
Disabled
sary to manually enter a static IP address that does not conflict
with other devices on the network.
3.7.8.2 Local IP address
If you intend to set up your client computers manually (no
DHCP), make sure that the assigned IP address is in the same
range as the default router address and that it is unique to your
private network. However, it is highly recommend to use DHCP
if that option is available on your network. An IP address alloca-
tion scheme will reduce the time it takes to set-up client com-
puters and eliminate the possibilities of administrative errors
and duplicate addresses. To manually configure the IP address
of the controller, move the cursor bar to Local IP address item,
then press the Enter key to show the default address setting in
the RAID controller. You can then reassign the static IP address
of the controller.
