BIOS CONFIGURATION
62
3.7.2.5 Activate Raid Set
The following screen is used to activate the RAID set after one
of its disk drive was removed in the power off state.
When one of the disk drives is removed in power off state, the
RAID set state will change to “Incomplete State”. If user wants
to continue to work while the SAS RAID controller is powered
on, the user can use the “Activate Incomplete Raid Set” option
to active the RAID set. After user selects this function, the RAID
state will change to “Degraded Mode” and start to work.
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Raid Set Function
Raid Set Function
Create Raid Set
Delete Raid Set
Expand Raid Set
Offline Raid Set
Activate Raid Set
Create Hot Spare
Delete Hot Spare
Rescue Raid Set
Raid Set Information
Activate Raid Set
Select Raid Set To Activate
Raid Set # 000
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Raid Set Function
Raid Set Function
Create Raid Set
Delete Raid Set
Expand Raid Set
Offline Raid Set
Activate Raid Set
Create Hot Spare
Delete Hot Spare
Rescue Raid Set
Raid Set Information
Offline Raid Set
Select Raid Set To Offline
Raid Set # 000
Offline Raid Set
es
No
Yes
Are you Sure?
No
Yes
