ARCHTTP PROXY SERVER INSTALLATION
136
5.2 For Linux
You should have administrative level permissions to install SAS
RAID software. This procedure assumes that the SAS RAID
hardware and Linux are installed and operational in your system.
The following installation procedure explains how to install the SAS
RAID software for Linux. The ArcHTTP proxy server is provided
on the software CD delivered with SAS RAID controller card or
download from the www.areca.com.tw. The firmware embedded
McRAID storage manager can configure and monitor the SAS RAID
controller via ArcHTTP proxy server.
1. Login as root. Copy the ArcHTTP file to a local directory.
(a). Insert the SAS RAID controller CD in the CD-ROM drive.
(b). Copy <CD-ROM>\PACKAGES\Linux\http directory to local
(Ex:/usr/local/sbin). or
(c). Download from the www.areca.com.tw or from the email
attachment.
2. You must have administrative level permissions to install SAS
RAID controller ArcHTTP proxy server software. This procedure
assumes that the SAS RAID hardware and driver are installed
and operational in your system.
The following details are the installation procedure of the SAS
RAID controller for Linux ArcHTTP proxy server software.
(a). Run the ArcHTTP proxy server by using the following
command:
Usage: ./archttp32 (TCP_PORT) or ./archttp64 (TCP_PORT).
It depends on your OS version.
Parameters: TCP_PORT value= 1~65535 (If TCP_PORT
assigned, ArcHTTP will start from this port. Otherwise, it will
use the setting in the archttpsrv.conf or default 81). This
is the port address assigning for the ArcHTTP configuration
(Cfg Assistant). Such as: archttp64 1553
